Description

These updated S1-C plans were produced using CAD, and incorporate many refinements and improvements over the original plans. This version includes the longer fuselage which is now considered the standard S1 version (this fuselage is also found on the S1-S). If you are building an S1-C or S1-SS, these are the plans you need to use. If you are restoring an older S1-C, be aware that it may have been built using the older plans hand-drawn by Curtis Pitts (these are also available from us). Please call us if you’re not sure which version you need for your particular aircraft.

NOTE 1: If you wish to build the S1-SS ‘Super Stinker’ version, or the four-aileron version of the S1-C wings, you will need these S1-C plans to build the fuselage and tail, as well as the supplemental wing-only drawings for those versions.

NOTE 2: While these modern “CAD Plans” were produced using CAD software, they do NOT consist of electronic CAD files – they are printed on paper. Sorry, but we can not release our proprietary CAD source files, or provide our aircraft plans in electronic or machine-readable format!
